GENERAL INFORMATION
Manufacturer
Arctic Cat
Model Year
2022
Model
Blast M 4000 ES
Model Code
S2022JABA1USO
Color
Dynamic Charcoal / Orange
DIMENSIONS
Length
Overall chassis – 128 in.
Height
Overall chassis – 38.5 in.
Width
Overall chassis – 44 – 46 in.
ENGINE & DRIVETRAIN
Engine
4000 Series, 2-Stroke
Cylinders
1
Cooling
Liquid
Coolant System Capacity – 5 qt.
Front / Long Tunnel Heat Exchanger
Displacement
397 cc
Bore x Stroke
85 x 70 mm
Fuel System
Electronic Fuel Injected (EFI)
Starting
Electric Turn-key
Ignition
Digitally Controlled CDI
270 W @ 3000 rpm
Lubrication
Electric Injection
Drive System
Arctic Drive System
Drive Clutch
CVTech Trailbloc
Driven Clutch
CVTech Invance
Drive Sprocket
Track – 8 Tooth, Involute
Clutch Calibration
0-5,000 ft.
Reverse
Push-Button Engine
Transmission
Gearing – 19 / 50
Chain Pitch – 90
Exhaust
APV with Tuned Pipe, Pipe Sensor, Manifold and Stainless Steel Muffler
Brakes
Stealth Hydraulic Master Cylinder with Lightweight Caliper
Fuel Type
Minimum Octane – 91
Fuel Capacity
11.7 gal.
Oil Capacity
3.25 qt.
OPERATIONAL
Handlebar
Hooked with Grab Handle, 4.5 in. Riser
Instrumentation
Digital gauge
Speedometer, Tachometer, Odometer, and Fuel – Hours
Oil / Coolant Indicator Light
Seating or Rider capacity
Mid-Size
Skis
Type – G2 ProClimb
Width – 7 in.
Ski Stance
37 – 39 in. Adjustable
Carbide
Runner Type – Single Runner
Track Type
Challenger
Track LxWxH
146 x 15 x 2 in.
Pitch
2.86 in.
OTHER
Additional Colors
Dynamic Charcoal / Orange
Dynamic Charcoal / Fire Red
Includes
4 in. Low-Height Windshield, Hand and Thumb Warmer, Tether Switch
Safety Features
Lighting – Halogen 1-Bulb
